As a product built to the DMR standard, PD705/705G(PD705G is the model with GPS) is endowed with ergonomic design , all round digital functions and remarkable quality to refresh your experience and enable you to be responsive to emergent situations. Superior digital voice, submersible with IP57 rating.
The globally patented industrial design and antenna design ensure convenient operation and remarkable GPS performance.
PD705/705G is strictly compliant with MILSTD- 810 C/D/E/F and IP57 standards, ensuring outstanding performance even under harsh environments.
With the combined application of narrowband codec and digital errorcorrection technologies, PD705/705G is capable of ensuring you superior voice under noisy environments or at the edge of the coverage area. In addition, the adoption of the AGC technology also optimizes your voice. With a built-in 1W speaker, PD705/705G ensures clear and crisp voice communication.
Compared with an analogue radio, PD705/705G can obtain an extra 40% operation time.
Benefiting from the TDMA technology, PD705/705G allows twice the channels based on the same spectrum resource. This is a big help to relieve the stress of increasing shortage in spectrum resource.
With this feature, the free slot can be allocated to a member that needs to communicate, effectively enhancing frequency efficiency and allowing you to communicate timely under emergent situations.
Besides the intrinsic encryption of the digital technology, PD705/705G provides enhanced encryption capability (such as 256-bit encryption algorithm) and the Scrambler feature (selectable).
In addition o conventional communication services, PD705/705G features rich data services and selectable functions such as Scan, Emergancy, Man Down (optional), High-speed Data Transmission* and Lone worker*.
The reserved port in PD705/705G allows users or any third party to further develop other helpful functions (GPS, Call Control and Telemetry).
General |
|
Frequency Range |
VHF: 136 – 174 Mhz UHF1: 400 – 470 Mhz UHF3: 350 – 400 Mhz |
Channel Capacity |
32 |
RF Power Output |
VHF: High Power 5W VHF: Low Power 1W
UHF1/ UHF3: High Power 4W UHF1/ UHF3: Low Power 1W |
Rated Audio Power Output |
0.5W |
Battery Life (5-5-90) |
Analog: 10.5 Hours Digital: 14.0 Hours |
Dust and Water Ingress Protection |
IP 57 Standard |
Weight |
335g |
Dimensions H x W x D (Without Antenna) |
135mm x 55mm x 35mm |
Contact us today with your requirements.
