- Digital & Analogue
- Emergency button
- Lone Worker
- Man Down
- GPS
- Bluetooth
- Vibrate Alert
- Real Time Clock
- On Board Voice Recording *chargeable license key
- Standard encryption – 256 bit AES encryption via chargeable license key
- Colour display (PH660 & PH690)
- Pre-defined or free dial text – Radio model dependant
- Max/Min Volume configured via CPS
- One Touch Call to enter the specified menu:
- Control Services – stun, revive, alert call etc
- Radio Alias: Sending and receiving calling radio’s alias – no fleet contact list reprogramming
- Voice with GPS: GPS information is embedded in the voice complying with standard protocol.
- Programming via Menu: Channel parameters can be programmed through the menu.
- Quick Dial: The radio can trigger the predefined function by dialling a number.
- Analogue Howl Suppression: Support handling of disturbance to audio signal and noise cancellation to improve voice quality on an analogue channel
General
- Digital Protocol ETSI TS 102 361-1, -2, -3
- Frequency UHF1: 400-470MHz; VHF: 136-174MHz
- Channel Capacity 32 (PH600) / 1024(PH660)
- Zone Capacity 2 (PH600) / 64(PH660)
- Channel Spacing 12.5kHz/20KHz/25KHz
- Frequency Stability }0.5ppm
- Operating Voltage 7.4V
- Battery Capacity 2600mAh
- Battery Life (5:5:90) 16 hours (Analog) / 20 hours (Digital)
- Size (H×W×D) 100×54.5×36.5mm (Without Antenna)
- Weight About 290g (PH660) / 270g (PH600)
- Screen 1.74” Transflective LCD, 240×180 (PH660)
- Vocoder AMBE++
- Bluetooth BT2.1+EDR / 4.0 (optional)
- Location GPS / GLONASS (optional)
- Man down / Vibration Support
- Real-time Clock Support (PH660)
- Encryption Support SW and HW Encryption (Optional)
GPSPS
- Accuracy specs are for long-term tracking (95th percentile values>5satellites
- visible at nominal -130 dBm signal strength)
- TTFF (Time to First Fix) – Cold
- Start <60s
- TTFF (Time to First Fix) – Hot
- Start <10s
- Horizontal Accuracy <10m
Environmentalnvironmentalvironmental
- Operating Temperature -30°C ~ +60°C
- Storage Temperature -40°C ~ +85°C
- ESD IEC 61000-4-2 (level 4) }8kV (Contact)}15kV (Air)
- Dust and Water Resistance IP68
- Reliability MIL-STD-810 G
Receiver
- Sensitivity (Analog) 0.22uV (12dB SINAD)
- Sensitivity (Digital) 0.22uV (5% BER)
- Adjacent Channel Selectivity
- 60 [email protected]/70 dB@20/25KHz (TIA603A) -1T
- [email protected] /70 dB@20/25KHz (TIA603D) -2T
- [email protected] /70 dB@20/25KHz (ETSI)
- Intermodulation 70 dB (TIA603D) / 65 dB (ETSI)
- Spurious Rejection 70 dB (TIA603D) / 70 dB (ETSI)
- Blocking or Desensitization 80dB (TIA603D) / 84dB(ETSI)
- Co-channel Rejection -12~0 dB @12.5KHz/-8~0 dB @20/25KHz
- Hum and Noise -40 [email protected] /-43 dB@20KHz /-45 dB@25KHz
- Rated Audio Power 0.5W
- Max Audio Power 2.0W
- Audio Distortion @ Rated
- Audio ≤3% (Typical)
- Audio Response +1~-3dB (TIA603D)
- Conducted Spurious Emission -57 dBm (TIA603D)
Transmitter
- Power Output 1W/4W (UHF1), 1W/5W (VHF)
- FM Modulation 12.5KHz: 11K0F3E / 20KHz: 14K0F3E / 25KHz:
- 16K0F3E
- 4FSK Digital Modulation
- 12.5KHz Data Only: 7K60F1D&7K60FXD
- 12.5KHz Voice Only: 7K60F1E&7K60FXE
- 12.5KHz Voice and Data: 7K60F1W
- Conducted/Radiated Emission -36dBm ≤1GHz; -30dBm >1GHz
- Modulation Limiting }2.5KHz @12.5KHz /}4KHz @20KHz /}5.0KHz
- @25KHz
- FM Hum and Noise -40 [email protected] /-43dB@20KHz /-45 dB@25KHz
- Adjacent Channel Power 60 [email protected] /70 dB @20/25KHz
- Audio Distortion @ Rated
- Audio ≤3% (Typical)
- Audio Response +1~-3dB (TIA603D)
